Operational limitations
Pressure: ≤ 2MPa
Speed: ≤ 20m/s
Temperature: -30 ℃~+204 ℃
Rotating Ring (SiC/C/TC)
Fixed ring (SiC/TC)
Secondary mechanical seal (fluororubber/sealing ring/PTFE)
Metal corrugated pipe (SUS316L/AM350/Inconel718)
/Titanium/Hastelloy C/Alloy-20)
Other parts (SUS304/SUS316/Titanio/Hastelloy C)
Operational limitations
Pressure: ≤ 2MPa
Speed: ≤ 20m/s
Temperature: -30 ℃~+204 ℃
Rotating Ring (SiC/C/TC)
Fixed ring (SiC/TC)
Secondary mechanical seal (fluororubber/sealing ring/PTFE)
Metal corrugated pipe (SUS316L/AM350/Inconel718)
/Titanium/Hastelloy C/Alloy-20)
Other parts (SUS304/SUS316/Titanio/Hastelloy C)
